RODECaster Video S Video & Audio Production Console

New

Overview

Print Email a Friend

The RØDECaster Video S is a professional all-in-one video switcher and audio production console designed for podcasters, videographers, livestreamers, YouTube creators, churches, and content studios who demand broadcast-quality results without complex gear setups. Combining multi-camera switching, studio-grade audio processing, direct streaming, ISO recording, wireless mic integration, and custom scene creation, it delivers everything you need to produce high-impact video podcasts and live productions from a single compact unit.

Features

All-in-One Video & Audio Console: Integrated video switcher and broadcast-quality audio mixer in one compact unit
Multi-Camera Switching: Connect up to four video sources (HDMI, USB-C, NDI) with smooth transitions
Studio-Grade Sound: High-gain Revolution Preamps™ with built-in APHEX® processing for professional podcast audio
Auto Camera Switching: Audio-based switching automatically changes angles for hands-free production
Direct Livestreaming: Stream via Wi-Fi or Ethernet to major platforms without extra hardware
ISO Recording: Record individual video and audio tracks for flexible post-production editing
Wireless Mic Ready: Built-in wireless receiver support plus Bluetooth connectivity
Custom Scenes & Overlays: Create branded layouts, picture-in-picture and chroma key effects
Touchscreen and Physical Controls: Fast, intuitive control designed for live environments
Compact Studio Design: Portable solution for video podcasts, interviews, livestreams and content studios

Specifications

Video Inputs & Outputs
- Video Input Feeds: 4 simultaneous video sources (3 × HDMI + 1 × USB-C)
- HDMI Inputs: 3 × Type-A (1080p, HDMI 1.4b)
- USB Video Input: 1 × USB-C (UVC video support)
- Video Output: 1 × configurable HDMI (Program / Preview / Multiview / Inputs 1–4)
Video Format & Frame Rates
- Supported Resolutions: 1920×1080p up to 60 fps
- Interlaced Support (HDMI): 1080i (25, 29.97, 30 fps)
- Color & Bit Depth:
  – Video Engine: 4:4:4 RGB / 8-bit
  – HDMI Input: 4:4:4 RGB, 4:4:4 YUV, 4:2:2 YUV / 8-, 10-, 12-bit
  – USB Input: 4:2:2 YUV / 8-bit, 4:2:0 YUV (NV12)
  – HDMI Output: 4:4:4 RGB / 8-bit
Conversion & Network
- Format/Frame Rate Converters: On all HDMI and USB inputs
- NDI Protocols: Single TCP, Multicast
- NDI Video Codecs: H.264, HEVC/H.265 (4:2:0, 8-bit)
- NDI Audio Codecs: AAC-LC, L-PCM Stereo 2.0 @ 48 kHz
Audio Inputs & Outputs
- Analog Audio Inputs: 2 × Neutrik® combo XLR/TRS (mic/line/instrument) with ultra-low-noise, high-gain Revolution Preamps™
- Wireless Audio: Dual internal RØDE Series IV receivers
- Bluetooth: Wireless audio input support
- Headphone Outputs: Typically 2 × ¼″ headphone jacks
Processing & Effects
- APHEX® Audio Processing: EQ, compressor, noise gate, high-pass filter, de-esser, Aural Exciter™, Big Bottom™, Compellor™
- Internal Audio Channels: Up to 9 stereo audio channels (mix & processing)
Streaming & Recording
- Direct Streaming: RTMP/RTMPS via Wi-Fi 6 or Ethernet
- Recording: Program H.264/MP4 (embedded AAC)
  ISO recording: separate video and audio tracks to external USB storage (exFAT)
- Supported Platforms: YouTube Live, Twitch, Facebook Live, Twitter/X Live & custom RTMP servers
Control & Interface
- Touchscreen: 2" high-resolution touchscreen display
- Front Controls:
  – 4 dedicated video source buttons
  – 5 customizable scene buttons
  – 4 assignable function buttons
- Rotary Encoder: For transitions, setting adjustments
- Inspect Feature: Quick preview and configuration of inputs and scenes
Connectivity
- Ethernet: Gigabit (10/100/1000 Base-T)
- Wi-Fi: Wi-Fi 6 (2.4 GHz & 5 GHz)
- Bluetooth: v5.3 support (audio/controls)
- USB: USB-C PD 45W (20 V, 2.25 A) for power/host connectivity
Power & Mechanical
- Power Supply: USB-C PD 45 W (20 V, 2.25 A)
- Dimensions: ~253.5 × 128.4 × 60.2 mm
- Weight: ~875 g
Media & Storage
- Internal Storage: ~24 GB onboard (20 GB user-configurable for graphics, media)
- External Storage: USB mass storage via USB-C (ISO & program recordings)
Format Support
- Video Input Limit: Up to 1080p; no native 4K support (accepts downscaled 4K)

Kit includes

2 x RODE RØDECaster Video S All-in-One Audio/Video Console
1 x Power Supply
1 x SC27 SuperSpeed USB-C to USB-C Cable
Limited 2-Year Manufacturer Warranty

All purchases are subject to our Terms & Conditions.
Images and script subject to copyright Photoshack 2026.

RODECaster Video S Video & Audio Production Console

RØDECaster Video Podcast & Livestream Console

$1,799.00

Website price only

Main Highlights
Produce broadcast-quality video podcasts without separate mixers, switchers or capture cards
Save time with intelligent auto-switching — perfect for solo creators and small studios
Stream and record simultaneously with professional redundancy
Future-proof your setup with HDMI, USB-C, NDI, wireless mic and network connectivity

Quantity

Apply for Finance Price Match Request

In Stock*

Usually ships within 1-2 Business Days

Term

Available from
$88.83 per week

Code: RODRCVS

At Photoshack, you don't need to wait to get the things you want'
You can apply for a loan to cover your purchases in-store and on line. The application form is quick and easy to complete.

Our finance options offers secured loans, with competitive interest rates, flexible terms and payments to suit your preferences.

Disclaimer

All payments listed on the page are indicative only.
Credit Criteria applies. From no deposit.
Please refer to the finance options below for more information.
Before applying, please contact us for availability of products.
