  • Overview
Print

The BOYA BY-WM8R is a compact and rugged beltpack audio receiver. With two channels, it can work with two transmitters simultaneously. It’s compatible with BY-WXLR8, BY-WHM8, BY-WM8T and BY-WM6 transmitter. The receiver features both a phone output for earphone monitoring as well as an output for connecting to the input of a camera with the included stereo mini cable. An optional stereo to dual XLR cable is available for connecting to a professional camera. The unit also comes with a shoe mount and locking adhesive strips for attaching to a camera or camcorder.

We also sell Shure, Rode, Saramonic, Tascam, Zoom and more

Features

  • UHF Receiver with 48 channels
  • Dual-Channel Receiver
  • Wirelessly syncs with transmitter for easy setup
  • OLED Display
  • Adjustable Mono, Stereo, Mono-A, Mono-B
  • Operation range can reach up to 100m
  • Powered by two AA Batteries

Specifications

  • Oscillator type: PLL Synthesized Control Oscillator
  • Antenna: Flexible
  • Channel group: A or B
  • Carrier Frequency Range: 576.4 MHz-599.9 MHz (Channel group: A) 568.6 MHz-592.1 MHz (Channel group: B)
  • Audio input connector: 3.5mm mini jack
  • Signal-to-noise ratio: 80 dB
  • Distortion: 0.8% (-60 dBV, 1 KHz input)
  • Earphone output level: 60 mW, 32 Ohms/1KHz
  • Audio output level: 120 mV
  • Power supply: Two AA batteries
  • Accessories: 3.5mm audio cable, shoe mount
  • Dimensions: (H x W x L) 7.7” x 3.1” x 1.1”(19.6 x 8.0 x 2.9cm)
  • Weight: 130g (4.6 oz) without batteries

Compatibility

  • BY-WXLR8 transmitter
  • BY-WHM8 transmitter
  • BY-WM8T transmitter
  • BY-WM6 transmitter

Kit Includes

  • 1 x BY-WM8T Transmitter
  • 1 x Stereo 3.5mm mini plug adapter
  • 1 x Cold Shoe Mount Adaptor
  • 1 x XLR to TRS adapter
  • 1 x User Manual

All purchases are subject to our Terms & Conditions.
Images and script subject to copyright Photoshack 2018.

Boya BY-WM8R Professional UHF Dual-Channel Wireless Receiver

$191.75

$263.95

Website price only

Main Features

  • UHF Receiver with 48 channels
  • Dual-Channel Receiver
  • Wirelessly syncs with transmitter for easy setup
  • Adjustable MONO, Stereo, MONO-A, MONO-B

Usually ships within 5-20 Business Days

Product code: BYWM8R
